Technical parameters |
|---|
| Length of the working table |
47.2 in |
| Width of the working table |
22 in |
| Maximum table load (evenly distributed) |
2204.6 lb |
| Power of the spindle drive |
17.4 hp |
| Number of CNC controlled axles |
3 pcs |
| Number of synchronous axles |
3 pcs |
| Number of tools in the magazine |
60 pcs |
| Minimum rotary speed of the vertical spindle |
100 1/min |
| Maximum rotary speed of the vertical spindle |
10000 1/min |
| Minimum distance of the spindle from the table |
5.9 in |
| Maximum distance of the spindle from the table |
27.6 in |
| Travel length X-axis (mechanical feed) |
40.7 in |
| Travel length Y-axis (mechanical feed) |
22 in |
| Travel length Z-axis (mechanical feed) |
20.1 in |
| Maximum feed rate in X-axis |
1.2 in/s |
| Maximum feed rate in Y-axis |
1.2 in/s |
| Maximum feed rate in Z-axis |
1.2 in/s |
| Total power demand |
26.8 hp |
| Machine height |
114.2 in |
| Machine length |
141.7 in |
| Machine width |
114.2 in |
| Machine weight |
5676.9 short ton |
