Technical parameters |
|---|
| Maximum turning length (Z-axis) |
78.7 in |
| Turning diameter over bed (max) |
36.2 in |
| Turning diameter over cross slide (max) |
21.7 in |
| Maximum feed rate in X-axis |
315 in/min |
| Maximum feed rate in Z-axis |
0 ft/min |
| Maximum power of the main spindle |
29.5 hp |
| Diameter of the spindle bore |
5.1 in |
| Minimum rotary speed of the main spindle |
8 rpm |
| Maximum rotary speed of the main spindle |
1500 rpm |
| Total number of tools in the turret |
4 pcs |
| Tailstock quill diameter |
4.5 in |
| Maximum travel length of the tailstock quill |
15.7 in |
| Total power demand |
40.2 hp |
| Weight of the lathe |
7.7 short ton |
