CNC Lathe DOOSAN PUMA 600 LM

Category CNC Lathes and Turning Centers DOOSAN ›
Manufacturer DOOSAN ›

ARCHIVED AD
CNC Lathe DOOSAN PUMA 600 LM was manufactured by the machine manufacturer DOOSAN. Machine DOOSAN PUMA 600 LM was built in 1997 year.

General data

Location United States
region New York
Year of manufacture 1997
Warranty Without warranty
Stock number 60418

Technical parameters

Maximum turning length (Z-axis) 126 in
Turning diameter over bed (max) 40.6 in
Turning diameter over cross slide (max) 31.5 in
Maximum travel length in the X-axis 18.5 in
Maximum power of the main spindle 60 hp
Diameter of the spindle bore 6 in
Maximum rotary speed of the main spindle 1800 rpm
Total number of tools in the turret 12 pcs
Length of the lathe 290 in
Width of the lathe 109 in
Height of the lathe 102 in
Weight of the lathe 23.8 short ton

Equipment

FANUC 21i-TB
Chip transporter
Hydraulic chuck
